Road Star Tower Ladders

  • Ideal for Electrical works, Domestic purpose, or any Industrial job at a height.
  • Manufactured from High Tensile Aluminum Alloys.
  • An economical variety in aluminum tower, extending section adjusts Intermediately
  • Reinforced with M.S. railing to enable safe and easy climbing.
  • Elegant, sturdy, light in weight, extremely useful where no wall Support is available to ladders
  • Having Solid rubber shoe to avoid surface scratching.
  • Section Size Width: Aluminum “C” Section(HE-30 Grade) Size: 66.6mm x 31.25mm
  • Material Standard: Confirm HE-30 Grade T-6 Temper, IS 733-1982
  • Step Details: Aluminum 25.4 mm Round Corrugated Tubes
  • Distance Between Two Steps- 12” Centre to Centre
  • Locking Facility: Pendulum Lock, Winch Gear Equipped with Dual Locking Facilities
  • Operating Facility: 01 No. Winch Gear Machine with required Wire Rope & Pulleys for Extending & Closing the Ladder
  • Size Of Top Platform: 18” X 21” (3-feet Below from Top)
  • Wheel : M.S. fabricated spoke type wheels mounted on axle, with leaf spring,
  • Other Features: Manila Rope, Pulley, Safety locks, Safety Ring, with rubber rib fitted with M.S. wheel
Available Sizes In 2- Section
Closed Height Extended Height
8 ft. 14 ft.
10 ft. 17 ft.
12 ft. 21 ft.
14 ft. 25 ft.
16 ft. 29 ft.
18 ft. 32 ft.
20 ft. 35 ft.



Available Sizes In 3- Section
Closed Height Extended Height
10 ft. 24 ft.
12 ft. 30 ft.
14 ft. 36 ft.
16 ft. 40 ft.
18 ft. 45 ft.
20 ft. 50 ft.
24 ft. 60 ft.
